Doughty - Twenty Clamp

£15.28 (inc V.A.T.) £12.73 (exc V.A.T.)
SKU:
DOUT58400
Weight:
0.30 KGS
Availability:
Please contact sales for stock and shipment information on: 020 8254 4840 or via  Sales@ShopWL.com
Shipping:
Calculated at checkout
Quantity:

Product Description

An innovative pressure die cast aluminium clamp that is suitable for 48mm to 51mm diameter tubes. It has a WLL of 20Kg and is 28mm wide. Slotted to hold captive an M10 nut or bolt head. Ideal for use with lightweight lanterns on trussing as it will not damage the cords. The perfect replacement for old style steel hook clamps. Available in powder coated black.

Technical Specification

Overview
WLL 20Kg
Tube Diameter 48-51mm
Finish Black
Clamp Width 28mm
Tube Diameter Ø48 - 51mm
Materials Main Body - EN46500 Aluminium
Roll Pins - Stainless Steel
Eyebolt Assy - Grade 8.8
Max Tightening Torque Hand-tight Only
Fixings To be used with M10 fixings
WLL 20Kg Vertical Load
Weight 0.28Kg
Factor of Safety 5:1
Approval TÜV Approved
Downloads
Data Sheet Download

Please Note: This product is intended for professional use only.
