Obsidian Control Systems - Netron EN12

£1,200.00 (inc V.A.T.) £1,000.00 (exc V.A.T.)
SKU:
OBS1330000066
Weight:
1.82 KGS
Availability:
Please contact sales for stock and shipment information on: 020 8254 4840 or via Sales@ShopWL.com
Shipping:
Calculated at checkout
Quantity:

Product Description

The Netron EN12 is a powerful high-density Ethernet to DMX gateway with twelve RDM compatible ports. Easy to configure with a range of integrated presets plus a wide array of advanced merge and routing features it is the ideal device for live production or installations requiring a lot of physical DMX ports. Contact closures allow for recall of presets, routings, mergers or any of the internal cues.

Features

  • RDM, Artnet and sACN support
  • Factory and user presets for plug and play setups
  • Line Voltage or POE powered
  • 1.8” OLED Display with rotary knob
  • 99 Internal cues with fade and delay time
  • Customizable routing and merging options
  • Remote configuration via internal webpage
  • Contact closures for cue or preset recall
  • Powder-coated aluminum rackmount housing
  • Unlocks ONYX NOVA 4 Universe License

Video

NETRON - EN12

The #NETRON #EN12 is a powerful high-density #Ethernet to #DMX gateway with twelve #RDM compatible ports.

Technical Specification

Specifications
Physical Length: 482.5 mm (19 in.)
Width: 146 (5.7mm)
Height: 44 mm (1.7 in.)
Weight: 1.82 kg (4 lbs)
Electrical 100-240 V nominal, 50/60 Hz
POE 802.3af
Power Consumption: 9W
Approvals / Ratings cETLus / CE / IP20
Connections
Front (12) 5pin DMX/RDM optically isolated ports
Ports are bidirectional for DMX In and Output
Full color OLED display
Encoder w. Push to Select / Exit Button
Back (2) Locking RJ45 Ethernet network In
(10) Contact Closures (Terminal Block)
Locking Power In/Thru
Downloads
User Guide Download
Data Sheet Download

Please Note: This product is intended for professional use only.
